RSP-150-3.3 Semi-enclosed Power Supply
£43.97
The RSP-150-3.3 constant current limiting switching power supply is for Rosahl M-7J1R, M-10J1R and MDL-7 membrane dehumidifiers. The input is 85 to 264V 50/60Hz with a 3V DC output. They are RoHS compliant and desiged for back of panel mounting. A DIN rail conversion is available . The active PFC function means there are lower losses, improved efficiency andreduced CO2 emissions.
Professional installation is advised.
Available on back-order
RSP-150 Series Features:
1U low profile 30mm
Built-in active PFC function with power factor close to 1 means there are lower losses, delivering a reduction in power and reduced CO2 emissions
- Built-in constant current limiting circuit
- Universal AC input / Full range
- Cooling by free air convection
- Remote ON-OFF control
- LED indicator for power on
- 100% full load burn-in test
Note: All switching power supplies need additional electrical protection and installation by a suitably qualified person avoid contact or injury from mains voltage electricity (100/200V AC).
| Membrane | Model | |
|---|---|---|
| M-7J1R MDL-7 |
RSP-150-3.3 | |
| M-10J1R | RSP-150-3.3 | |
Additional information
| Weight | 0.65 kg |
|---|---|
| Dimensions | 25 × 15 × 5 cm |
| Country of Origin | China |
| HS code | 85044083 |
