M-10J1R Membrane Dehumidifier

With a wider range of five models and simpler installation, the new M Series membranes are mounted in pre-drilled stainless steel frames and supplied with a pre-formed gasket. As with the existing MDL Series, multiple membranes may be used for larger enclosures.  A 3V dc current limiting power supply is required. M Series models are normally installed inside the enclosure.

A new way to protect sensitive equipment from moisture with our innovative micro dehumidifier. Perfect for enclosures, display cabinets, 3D print filament drying, and optical instruments. Compact, reliable, and maintenance-free—explore application-based solutions today!

Membrane Size Comparison Chart

Series	M-1J1R	M-2J1R	M-3M1R	M-3J1R	M-5J1R	M-7J1R	M-10J1R
Dehumidifying (grams/day)*1	1	2.0	2.9	4	8	16	29
Applicable volume m³ *2	0.125 m³	<0.25 m³	<0.35 m³	<0.5 m³	<1 m³	<2 m³	<4 m³
Element voltage				3V DC
Power consumption (W) *3	1.0	1.5	2	2	3	6	12
Dimensions (mm) *4	52.5 x 50 x 16.5	67.5 x 50 x 16.5	65 x 62 x 16.5	74 x 58 x 16.5	89 x 84 x 116.5	117 x 105 x 17.5	162.5 x 155 x 17.5
Weight (g)	70	85	90	95	150	340	580
Operating temperature	-10 to +50C	-10 to +50C	-10 to +50C	-10 to +50C	-10 to +50C	-10 to +50C	-10 to +50C
Terminals	Push connector	Push connector	Push connector	Push connector	Push connector	Push connector	Push connector

Additional information
